Features

• Mounts on commercial-spec sized carbine receiver extension tube (not included) from manufacturers such as Bushmaster, DPMS, Olympic, and others (please see the note below)
• Sloping cheek weld combines a slim profile with user comfort
• Shielded release latch prevents snagging and accidental operation
• Premium chrome-silicon lock spring provides positive locking and long service life
• Side mounting slots accept optional cheek risers for NON-AR15/M16 applications
• Replaceable 0.55" Extended Rubber Butt-Pad offers an anti-slip surface and increases impact protection
• Compatible with Magpul ASAP® and other receiver-mount sling attachments
• Sling Mounts

  • Rear/Bottom - 1.25" sling loops
  • Toe - Lanyard hole for custom para-cord rigs

Optional Accessories*

• Rubber Butt-Pad, 0.30"
• Enhanced Rubber Butt-Pad, 0.70:
• Cheek Risers (0.25", 0.50", 0.75" for NON-AR15/M16 applications)

Specifications*

• MOE, Commercial-Spec (stock configuration)

  • Weight: 0.53 lb.
  • Weight, w/ Rec. Extension: 0.86 lb.
  • Length, Maximum: 7.15 in.
  • LOP Adjustment Range: 3.80 in.
  • LOP, M4 Collapsed: 10.95 in.
  • LOP, M4 Extended: 14.75 in.

NOTE: There are two basic sizes of M4 Carbine receiver extensions (buffer tubes): mil-spec and commercial-spec.

* Specifications based on extended-length (slant-back) commercial-spec carbine receiver extension and may vary depending on tube manufacturer.
Extended Rubber Butt-Pad, 0.55" weight: 0.11 lb.
Optional Rubber Butt-Pad, 0.30" (weight: 0.08 lb.) and Enhanced Rubber Butt-Pad, 0.70" (weight: 0.13 lb.) may ONLY be used with the uncommon standard-length (flat-back) commercial-spec carbine receiver extensions.
